● 10.1-inch widescreen / 1280 * 800, 16: 10, capacitive touch screen
● Integrated Intel® J6412/2.0GHz quad-core, quad-thread processor.
● 2*SODIMM DDR4 2666MHz, supports up to 32GB.
● 1*HDMI
● 2*Intel I210AT Gigabit LAN card
● 6*RS232/485 (on 2*12P Phoenix terminals)
● 2*USB3.0, 4*USB2.0
● 9-36V wide voltage input
Model | P1081Y-F6 V1.0 (J6412) | |
Chassis | Material/structure | Aluminium alloy |
Color | Bright silver color | |
Size (LWH) | L263*W179*H61mm | |
Weight (bare net) | 2.1KG | |
Installation | Support VESA (75mm)/flush panel mounting | |
LCD Screen
| Type | 10.1’ LCD, Widescreen, 16:10 |
Resolution | 1280 * 800 | |
Brightness | 400 cd/m2 | |
Touch Screen
| Type | Capacitive, 10-point touch |
Transmittance | 80% or more | |
Motherboard
| CPU | Integrated Intel® J6412/2.00GHz Quad-Core Quad-Thread Processor, TDP power consumption 10W |
Display | Integrated Intel® UHD Graphics | |
Memory | 2*SODIMM DDR4 2666MHz memory, support up to 32GB | |
IO Interface
| POWER | 1*Power Switch, 1*One-Key Restore, 1*ACLOSS (Power-on DIP Switch), 1*CMOS Reset Switch |
LED | 1*Power Indicator, 1*Hard Drive Indicator | |
Display Interface | 1*HDMI1.4 | |
LAN | 2*Intel I210AT Gigabit power port, support Wake on LAN/PXE | |
USB | 4*USB3.0, 2*USB2.0 | |
COM | 6*RS232 /485 (on 2*12P Phoenix terminals) | |
Audio | 1*Line out, 1*Mic | |
Phoenix terminal
| 1*4P (1*PWR/1*P.LED) | |
2*12P (6*RS232/485) | ||
POWER | 1*DC or 1*2P Phoenix terminal, support 9~36V wide voltage input | |
Storage | MSATA | 1*MSATA |
M.2
| 1*M.2, support Key-M, 2260/2280, NVME PCIEx2 SSD (motherboard side) | |
1*M.2, support Key-M, 2280, SATA SSD (IO board side) | ||
Expansion
| M.2
| 1*M.2, Key-B support, 2242/2252, 5G module |
1*M.2, Support Key-E, 2230, WIFI Module | ||
System Support
| Windows | Windows 10 |
Linux | Ubuntu | |
Power Requirements | Power supply type | External Power Adapter |
Voltage Input | DC 9~36V wide voltage input | |
Power Output | AC to DC 60W or more (depending on specific equipment) | |
Environments | Operating Temperature | -10℃~50℃ |
Storage Temperature | -20℃~70℃ | |
Relative Humidity | 5%-95% relative humidity, non-condensing | |
Operating Vibration | 0.5g rms/5-500HZ/random/operating |
Order Information
No. | Model | CPU | Memory | Motherboard | IO Board | HDD | LAN | COM | HDMI | USB3.0 | USB2.0 | power |
1 | P1081Y-F6 V1.0(J6412) | J6412/2.0G | 2*SODDR4 | P641 | P1071-LED/P1041-F6 | MSATA+M.2(SATA)+M.2(NVME) | 2*I210 | 6 | 1 | 4 | 2 | 9~36V |
2 | P1081Y-F6 V1.0(7300U) | i5-7300U/2.6G | 2*SODDR4 | P67 | P1071-LED/P1041-F6 | MSATA+M.2(SATA)+M.2(NVME) | 2*I210 | 6 | 1 | 4 | 2 | 9~36V |
3 | P1081Y-F6 V1.0(8260U) | i5-8260U/1.6G | 2*SODDR4 | P81 | P1071-LED/P1041-F6 | MSATA+M.2(SATA)+M.2(NVME) | 2*I210 | 6 | 1 | 4 | 2 | 9~36V |
4 | P1081Y-F6 V1.0(10210U) | i5-10210U/1.6G | 2*SODDR4 | P102 | P1071-LED/P1042-F6 | MSATA+M.2(SATA)+M.2(NVME) | 2*I210 | 6 | 1 | 4 | 2 | 9~36V |
5 | P1081Y-F6 V1.0(5205U) | 5205U/1.9G | 2*SODDR4 | P102 | P1071-LED/P1042-F6 | MSATA+M.2(SATA)+M.2(NVME) | 2*I210 | 6 | 1 | 4 | 2 | 9~36V |
