10 cores, 12 threads | Up to 4.4GHz | 15W TDP Dual DDR5 – Up to 64GB, 4800MHz 4 independent displays – VGA + 2x HDMI + LVDS/EDP Dual Intel I210AT Gigabit LAN – Industrial-grade reliability M.2 NVMe PCIe 4.0 x4 + SATA 3.0 PCIe x4 expansion slot -10°C ~ 60°C operating temperature Long lifecycle support ✅CE Certified | FCC | RoHS | ISO9001 ✅ 3-Year Warranty | Free Support | 7 Year Supply

Intel Core i5-6300U – 2.4GHz dual-core, quad-thread, 15W TDP 2x DDR4 SODIMM – Up to 32GB, 2133MHz 2x RTL8111H Gigabit LAN – Wake-on-LAN & PXE support 6x COM ports – COM2 supports RS485/422 Triple display – VGA + HDMI + LVDS/EDP Triple storage – M.2 NVMe + mSATA + SATA 3.0 Mini-PCIe slot – For Wi-Fi or 4G module 8x USB (2 rear + 6 internal) -10°C to 60°C operating temperature ​✅CE Certified | FCC | RoHS | ISO9001 ✅ 3-Year Warranty | Free Support | 7 Year Supply

AMD Ryzen 7 8845HS – 8 cores, 16 threads, 3.8GHz (Turbo up to 5.1GHz) Built-in NPU – 16 TOPS AI computing power AMD Radeon 780M graphics – 4K/60Hz support 2x DDR5 SODIMM – Up to 64GB, 5600MHz 2x HDMI 2.0 – 4K@60Hz output Triple independent displays – 2x HDMI + LVDS/EDP 2x RTL8111 Gigabit LAN – Wake-on-LAN & PXE M.2 NVMe PCIe 4.0 x4 – Ultra-fast storage M.2 Key E – For WiFi/BT module ✅CE Certified | FCC | RoHS | ISO9001 ✅ 3-Year Warranty | Free Support | 7 Year Supply

LGA1151 socket – Supports 6th/8th/9th Gen Intel Core i3/i5/i7/i9, Pentium, Celeron 2x DDR4 SODIMM – Up to 64GB, 2666MHz, dual-channel 4x Intel I210AT Gigabit LAN ports – Industrial-grade reliability 1x HDMI + LVDS/EDP – Dual display support 1x M.2 NVMe PCIe 3.0 x4 + 1x SATA 3.0 1x PCIe 3.0 x4 slot DC 12-24V wide voltage input -10°C to 60°C operating temperature Compatible with VG390 series expansion boards ​✅CE Certified | FCC | RoHS | ISO9001 ✅ 3-Year Warranty | Free Support | 7 Year Supply

Intel Core i3-6100H – 2.7GHz dual-core, quad-thread, 35W TDP Intel HM370 chipset 2x DDR4 SODIMM – Up to 64GB, 2133MHz 2x HDMI + VGA – Triple independent displays (HDMI/VGA/LVDS/EDP) 2x RTL8111 Gigabit LAN – Wake-on-LAN & PXE 2x SATA 3.0 + M.2 NVMe PCIe 3.0 x4 – Flexible storage M.2 Key E – For WiFi/BT module 120-pin high-speed header – For expansion boards -20°C to 60°C – Wide operating temperature DC 12V power input

LGA1700 socket – Supports 12th/13th/14th Gen Intel Core i3/i5/i7/i9 (65W max) Intel H610 chipset 2x DDR4 SODIMM – Up to 128GB, 3200MHz Triple display – 2x HDMI 1.4 + VGA + LVDS 1x RTL8111H Gigabit LAN – Wake-on-LAN & PXE 2x SATA 3.0 + M.2 NVMe PCIe 3.0 x4 – Flexible storage M.2 Key E – For WiFi/BT module USB 3.2 (10Gbps) – High-speed data transfer 2x COM ports – COM2 supports RS485/422 DC 19V power input ​✅CE Certified | FCC | RoHS | ISO9001 ✅ 3-Year Warranty | Free Support | 7 Year Supply

Intel Alder Lake-N N97 – Quad-core, 3.6GHz, 12W TDP (ultra low power) 4x Intel I210AT Gigabit LAN – Industrial-grade networking POE support – Requires VL68-PW expansion board 6x COM ports – COM2/COM3 support RS485/422 Triple display – VGA + HDMI + LVDS/EDP 1x DDR4 SODIMM – Up to 16GB, 3200MHz M.2 NVMe PCIe x1 + SATA 3.0 – Flexible storage Mini-PCIe slot – For WiFi or 4G module 8x USB (rear + internal) 4-in/4-out GPIO -10°C to 60°C operating temperature

CE | FCC | RoHS | ISO9001 | 100% Burn-in Test 3-Year Warranty | 7 Year Supply | Free Tech Support | Global Shipping ​Intel Prestige Partner | 20+ Years Experience | Trusted in 30+ Countries

Intel® Celeron J1900/2.00GHz quad core processor, TDP 10W
