| Model number | P1071Y-C6 V1.0(8260U) |
| Case | Material/Structure | Aluminum alloy material, no fan cooling structure |
| Color | Silver |
| Dimension(L*W*H) | L272*W214*H62mm |
| Weight (bare weight) | 2.63 KG |
| Install | Support VESA/ embedded panel installation |
LCD scree | Type | 10.4 inch LCD |
| Resolution | 800 * 600 |
| luminance | 350 cd/m2 |
Touch scree | Type | Capacitive screen, 10 touch |
| Light transmittance | More than 85% |
| Motherboard | CPU | Integrated Intel®i5-8260U/1.60GHz quad-core eight-thread processor, TDP 15W |
| Reveal | Integrated Intel®UHD Graphics 620 |
| Internal memory | 2 x DDR4 SODIMM 2400 MHZ memory, supports a maximum of 64GB |
IO interface | POWER | 1* Power button, 1* one key restore (and reset switch to choose one), 1*ACLOSS (power on DIP switch), 1*CMOS reset switch |
| LED | 1* Power indicator, 1* hard disk indicator |
| USB | 24 x USB3.0, 2 x USB2.0 |
| LAN | 1*AC LOSS (power-on toggle switch) |
| Display interface | 1* SIM card slot, 3G/4G module application |
| COM | 6*RS232 serial port, COM1 ~2 RS232 DB9 serial port, of which COM2 supports RS485/422, COM3-6 RS232 on the 2*15pin Phoenix terminal, of which COM3 supports RS485, COM1-2 supports the 9pin live function |
| Phoenix terminal | 2*15Pin(4 in 4 out GPIO, switching signal, COM3~COM6, 5V VCC and GND) |
| Dip switch | 10-bit dip switch, COM2 to 3 RS232/485 switch, COM2 RS422 through the COM2_SW1 jumper |
| Audio frequency | 1*Line out, 1*MIC |
| Power source | 1*DC aviation interface or 1*2Pin Phoenix terminal, support 9~36V wide voltage input |
| Store | SATA | 1 x 2.5-inch hard disk |
| MSATA | 1*MSATA |
| M.2 | 1*M.2/SSD: Key-M, 2280, NVME PCIEx4 SSD |
| Extend | M.2 | 1*M.2/WiFi, supports Key-E, 2230, WiFi module |
| 1*M.2/5G, supports Key-B, 2242/52, 5G modules |
System Support | Microsoft Windows | Windows 10 |
| Linux | Ubuntu |
| Watch Dog | Support hardware reset function(L256, 0~255 seconds) |
| Power | Power supply type | External power adaptor |
| Voltage input | 9V~36V wide voltage |
| Power output | 60W~90W (depending on the device) |
| Environment | Operating temperature | -10℃～50℃ |
| Storage temperature | -20℃～70℃ |
| Relative humidity | 5%-95% relative humidity, no condensation |
| Working vibration | 0.5g rms/5-500HZ/random/operating |
