LGA1700 socket – Supports 12th/13th/14th Gen Intel Core i3/i5/i7/i9 (65W max) Intel H610 chipset 2x DDR4 SODIMM – Up to 128GB, 3200MHz Triple display – 2x HDMI 1.4 + VGA + LVDS 1x RTL8111H Gigabit LAN – Wake-on-LAN & PXE 2x SATA 3.0 + M.2 NVMe PCIe 3.0 x4 – Flexible storage M.2 Key E – For WiFi/BT module USB 3.2 (10Gbps) – High-speed data transfer 2x COM ports – COM2 supports RS485/422 DC 19V power input ​✅CE Certified | FCC | RoHS | ISO9001 ✅ 3-Year Warranty | Free Support | 7 Year Supply

Intel Alder Lake-N N97 – Quad-core, 3.6GHz, 12W TDP (ultra low power) 4x Intel I210AT Gigabit LAN – Industrial-grade networking POE support – Requires VL68-PW expansion board 6x COM ports – COM2/COM3 support RS485/422 Triple display – VGA + HDMI + LVDS/EDP 1x DDR4 SODIMM – Up to 16GB, 3200MHz M.2 NVMe PCIe x1 + SATA 3.0 – Flexible storage Mini-PCIe slot – For WiFi or 4G module 8x USB (rear + internal) 4-in/4-out GPIO -10°C to 60°C operating temperature

● Integrated Intel i3-N305/Turbo 3.8GHz, eight-core, eight-thread processor ● 1*SODDR4 3200MHz memory, up to 16GB ● 1*HDMI2.0, 1*DP1.4, 1*VGA ● 2*Intel I210AT Gigabit Ethernet ports ● 2*RS232/485 DB9 serial ports, COM1~2 support CAN (need to load CAN module) ● 2*USB3.0, 4*USB2.0 ● Support DC 12V

● Integrated Intel i5-1235U/1.3GHz, 10-core 12-thread processor ● 2*SODDR4 3200MHz memory, maximum 64GB ● 2*HDMI2.0, 1*DP1.4, 1*VGA, support quad display ● 2*Intel I210AT Gigabit Ethernet port ● 2*RS232/485 DB9 serial port, COM1~2 support CAN (need to load CAN module) ● 4*USB3.0, 2*USB2.0 ● Support DC 12V

● Integrated Intel N100 quad-core, quad-thread processor ● 1*SODDR4 3200MHz, support up to 16GB ● 2*HDMI2.0 ● 2*RTL8111H Gigabit power port ● 2*USB3.0, 3*USB2.0, 1*Type-C(5Gbps) ● DC12V power input ● Fanless cooling structure, all aluminium alloy material

● Integrated Intel i5-1135G7/2.4GHz, quad-core, eight-thread processor ● 2*SODDR4 3200MHz, up to 64GB ● 1*DP, 1*HDMI2.0, 1*VGA ● 6*Intel I210AT Gigabit ports, 4 of which support POE ● 4*RS232/485 DB9 serial ports ● 4*USB3.0, 2*USB2.0 ● Support DC 9~36V wide voltage ● Fanless cooling, copper tube heat conduction

● Integrated Intel i5-1135G7/2.4GHz, quad-core, eight-thread processor ● 2*SODDR4 3200MHz, up to 64GB ● 1*DP1.4, *HDM,2.0, 1*VGA ● 6*Intel I210AT Gigabit ports, 4 of them support POE ● 2*RS232/485 DB9 serial ports ● Support DIO 8 in 8 out with isolation ● 2 * USB3.0, 4 * USB2.0 ● Support DC 9~36V wide voltage ● Fanless cooling, copper tube heat conduction

● Integrated Intel i5-1235U/1.30GHz, 10-core 12-thread processor ● 2*SODDR4 3200MHz, up to 64GB ● 2*HDMI2.0, 1*DP1.4, 1*VGA ● 2*Intel I210AT Gigabit Ethernet ports ● 6*RS232/485 DB9 serial ports, COM1~2 support CAN (need to load CAN module) ● 4*USB3.0, 2*USB2.0 ● Support DC 9~36V wide voltage ● Fanless cooling

● Integrated Intel® Alder Lake-N N97/Turbo 3.6GHz Quad-Core Processor ● 1*SODDR4 3200MHz, supports up to 16GB ● 1*HDMI1.4 ● 4*Intel I210 Gigabit Ethernet ports ● 2*RS232/485 (located in 2*3P Phoenix terminal) ● 5*USB3.0, 1*USB2.0 ● DC12V power input ● Fanless cooling structure, all aluminium alloy material
