CPU: Intel® Celeron® 5205U dual-core 1.9 GHz, 15W TDP (8th/10th Gen Whiskey Lake-U / Comet Lake-U compatible) Memory: 1× SODIMM DDR4-2400, up to 32 GB Display: VGA + HDMI 1.4 + embedded DisplayPort, 4K capable Network: 1× Gigabit Ethernet (Wake-on-LAN/PXE) Storage/Expansion: SATA 3.0 (6Gbps), M.2 2280 NVMe/SATA, M.2 2230 Wi-Fi I/O: 4× USB 3.0, 2× USB 2.0, RS232, PS/2, HD audio with amplifier Power/Temp: 12V DC, -10°C to 60°C Size: 120 × 120 mm OS: Windows 10, Linux

CPU: Intel® J1900 quad-core 2.0 GHz, 10W TDP (Bay Trail) Memory: 1× SODDR3L 1600/1333 MHz, up to 8 GB Display: VGA + HDMI (sync/async) Network: 1× Gigabit Ethernet (Wake-on-LAN/PXE) Storage/Expansion: SATA 2.0, mSATA (SSD/Wi-Fi), Mini-PCIe (Wi-Fi/4G), SIM slot I/O: 5× USB 2.0, 1× USB 3.0, RJ45 console, HD audio Power/Temp: 12V DC, -10°C to 60°C, fanless Size: 120 × 120 mm OS: Windows 7/10, Linux

CPU: Intel® Celeron® J6412 quad-core 2.0 GHz, 10W TDP (Elkhart Lake) Memory: 1× SODIMM DDR4-3200, up to 32 GB Display: VGA + HDMI 2.0 (up to 4096×2304@60Hz) Network: 2× Gigabit Ethernet (Wake-on-LAN/PXE) Storage/Expansion: SATA 3.0, M.2 2280 NVMe PCIe x2, Mini-PCIe (Wi-Fi/4G) I/O: 4× USB 3.0, 2× USB 2.0, 2× RS232 (RS485 switchable), HD audio Power/Temp: 12V DC, -10°C to 60°C, fanless Size: 120 × 120 mm OS: Windows 10/11, Linux

CPU: Intel® J1900 quad-core 2.0 GHz, 10W TDP Memory: 1× SODDR3L 1600/1333 MHz, up to 8 GB Display: VGA + HDMI + dual-channel 24-bit LVDS (sync/async) Network: 2× Gigabit Ethernet (Wake-on-LAN/PXE) Storage/Expansion: SATA, mSATA, Mini-PCIe (Wi-Fi/3G), SIM slot I/O: USB 3.0 + USB 2.0, RS232, 4-ch GPIO, HD audio with amplifier Power/Temp: 12V DC, -10°C to 60°C, fanless Size: 120 × 120 mm OS: Windows 7/10, Linux

● Supports Intel LGA1700 / 12th–14th generation processors ● 2× SODDR5 memory slots, supporting up to 64GB ● 6× Intel I226V 2.5G Gigabit Ethernet ports ● 2× Intel I210AS Gigabit fibre optic ports ● Expandable to 4 or 2 fibre optic/Ethernet ports ● 1× VGA ● 2 × USB 3.0, 1 × built-in USB 2.0

CPU: Intel® J1900 quad-core 2.0 GHz, 10W TDP Memory: 1× DDR3L SODIMM, up to 8 GB Display: VGA + HDMI + dual-channel 24-bit LVDS (triple display) Network: 2× Gigabit Ethernet (Wake-on-LAN/PXE) Storage/Expansion: SATA 2.0, Mini-PCIe, mSATA, SIM slot I/O: 6× USB 2.0, 1× USB 3.0, 6× RS232 (COM3: RS485/RS422), 4-ch GPIO Power/Temp: 12V DC, -10°C to 60°C, fanless Size: 165 × 115 mm OS: Windows 7/10, Linux

● 23.8-inch LCD, 1920×1080, 16:9, capacitive touchscreen ● Supports Intel LGA1151/8th–9th generation processors ● 2× SODDR4, supports up to 64GB ● 1× HDMI, 1× VGA ● 1 × RTL8111H Gigabit Ethernet card ● 2 × RS232 DB9 serial ports ● 4 × USB 3.0, 2 × USB 2.0 ● 19V DC input ● Aluminium alloy construction, fan-cooled design

11th Gen Tiger‑Lake‑U On‑board CPU: Mini‑ITX industrial motherboard with soldered i7‑1195G7 (4C/8T), compatible with Tiger Lake‑U series CPUs. Dual DDR4‑3200 SODIMM up to 64GB memory. Multi‑display Output: Intel Iris Xe graphics support 4K resolution; VGA, dual‑HDMI, selectable LVDS/eDP, enabling four independent display outputs. Dual LAN & Abundant I/O: 2× Intel I210AT Gigabit LAN with WOL/PXE; 2× configurable RS232/422/485 serial ports, multiple USB3.0/2.0, GPIO and power‑amplified audio.

LGA1150 H81 PlatformSupports: LGA1150 Intel CPU, dual‑channel DDR3 up to 16GB for industrial computing. Dual Gigabit LAN & Multiple Displays: 2× Intel I210AT LAN, VGA, HDMI and 24‑bit LVDS, with 2× configurable RS232/422/485. Flexible Storage & Expansion: SATA 3.0, M.2 Key‑M NVMe/SATA and M.2 Key‑E for Wi‑Fi/Bluetooth modules. Industrial‑Grade Functions: Built‑in hardware watchdog, 4‑channel GPIO and power‑amplified audio output. Compact Reliable Design: 170×170 mm Mini‑ITX, DC12V power,‑10℃‑60℃
