LGA1700 socket with Intel W680 chipset, supports Core i9/i7/i5/i3 processors, and up to 128GB DDR4 3200MHz memory. 2 HDMI 1.4 (4096x2160) + 1 VGA, ideal for digital signage and industrial workstations. 8 SATA 3.0 (RAID 0/1/5/10) plus 1 M.2 NVMe PCIe 4.0 x4 for ultra-fast SSD. Dual Intel GbE LAN, 6 x COM (RS232/485/422), 4 x USB 3.2 Gen 2 (10Gbps), M.2 Key B for 4G/5G, and multiple PCIe/PCI slots. Operates from -20°C to 60°C, hardware watchdog timer, ATX power, and supports Windows/Linux.

Supports LGA1700 12th/13th/14th Gen Intel® Core™ i3/i5/i7/i9 processors Honored as Intel Prestige Partner CE Certified | FCC | RoHS | ISO9001 3-Year Warranty | Free Support | 7 Year Supply

Supports Intel 12th/13th/14th Gen LGA1700 processors (Celeron to Core i9). 4 x DDR5 DIMM slots, dual-channel, up to 5600MHz, max 192GB. Four HDMI 2.0 ports with 4K @ 60Hz output, ideal for multi-display setups. Dual 2.5GbE LAN (RTL8125B) plus PCIe 5.0 x16 and PCIe 4.0 x4 slots. Rich storage & I/O: 4 SATA 3.0, 2 x M.2 (PCIe 3.0/4.0 x4), 12 USB ports, RS232, and hardware watchdog timer.

Supports LGA1700 Intel 12th/13th/14th Gen Core i3/i5/i7/i9 & Xeon processors with Intel W680 chipset. 4 x DDR5 DIMM slots, dual-channel up to 5600MHz, 128GB max, with ECC memory support. Rich display options: 4 x HDMI 1.4 + 1 x VGA port. Triple Gigabit LAN (2 x I210AT + 1 x I226LM) with vPRO, Wake-on-LAN, and PXE support. Industrial-grade expansion & I/O: 2 x PCIe 5.0 (x8), 3 x PCIe x4, 2 x PCI, 8 x SATA 3.0, 6 x RS232 (COM1/2 support RS485/422), and wide operating temperature (-20°C to 50°C

​LGA1155 supports Intel 2nd/3rd Gen Core i3/i5/i7/Celeron/Pentium processors. Intel B75 chipset, 2×DDR3 up to 16GB (1066/1333/1600MHz). Display: 1×VGA + 1×HDMI 1.4, supports dual and extended display modes. Dual Intel I210AT Gigabit LAN with Wake-on-LAN/PXE, plus expansion: PCIe x16, PCIe x4, and 2×PCI. Industrial I/O: 6×COM (2 with RS485/422), 4×USB 3.0 (2A/port), LPT, GPIO, mSATA, and -10°C~60°C operation.

LGA1700 supports Intel 12th/13th/14th Gen Core processors. Intel W680 chipset, 4×DDR5 ECC up to 128GB, 5600MHz. Display: 1×VGA + 2×HDMI 1.4. Dual Intel I210AT Gigabit LAN, expansion: PCIe 5.0 (x8), PCIe 4.0 x4, PCIe 3.0 x4, and 1×PCI. Industrial I/O: 6×COM (2 with RS485/422), 8×SATA3, 2×M.2, LPT, PS/2, -20°C~60°C operation.

Supports LGA1151 6th/7th/8th/9th Gen Intel processors (Celeron to Core i7, up to 95W) with Intel Q270 chipset. ​4 x DDR4 DIMM slots, dual-channel up to 2666MHz, maximum 128GB capacity. Flexible display outputs: 1 x VGA + 2 x HDMI 1.4, supporting single, dual, and extended display modes. Rich legacy & industrial I/O: 2 x PCI, 3 x PCIe 3.0 x4, 1 x PCIe x1, 6 x RS232 (2 with RS485/422 + 5V/12V), LPT, PS/2, and mSATA. Dual Intel I210AT Gigabit LAN with Wake-on-LAN/PXE

Supports LGA1700 12th/13th/14th Gen Intel® Core™ i3/i5/i7/i9 and Xeon processors

​LGA1151 supports 6th–9th Gen Intel Core processors. Intel H110, 2×DDR4 up to 64GB. Display: 1×VGA + 2×HDMI 1.4. Dual Intel I210AT Gigabit LAN, 1×PCIe x16, 1×PCIe x4, 5×PCI slots. Industrial I/O: 6×COM (2 with RS485/422), LPT, GPIO, TPM, -10°C~60°C.
