● Integrated Intel® Core i5-8260U processor (1.60GHz quad-core, eight threads) ● 2x SODDR4 2400MHz memory slots, supporting up to 64GB ● 1x HDMI 1.4, 1x HDMI 2.0, supporting dual display output ● 2x RTL8111H Gigabit Ethernet controllers ● 2x RS232/485 DB9 serial ports ● 4x USB 3.0, 4x USB 2.0, 1x SIM card slot ● DC 12V power input ● Fanless thermal design, full aluminium alloy construction

● Integrated Intel® i5-10210U/1.60GHz quad-core eight-thread processor ● 2*SODDR4 2666MHz memory, supports up to 64GB. ● 1*HDMI1.4, 1*VGA, support dual display ● 2*intel I211+1*Intel I210 Gigabit power port ● 6*RS232/485 DB9 serial port, COM5-6 support CAN ● 1*12PIN Phoenix terminal, four in four out GPIO, switch, 5V ● 4*USB3.0, 3*USB2.0, 1*USB2.0 built-in ● 9~36V wide voltage input ● Fanless cooling structure, all aluminium alloy material

​● Intel® Core™ i5-8260U processor, 1.60GHz quad-core with eight threads ● 2*SODDR4 2400MHz, supporting up to 32GB ● 1*HDMI, 1*VGA ● 2*Intel I225 + 4*Intel I210 ● 1*RS232/485 DB9 serial port, 1x Console port ● 4*DI，4*DO ● 4*USB 3.0 ports, 2*USB 2.0 ports, 1*internal USB 2.0 port ● DC 12V power input ● Fanless thermal design, full aluminium alloy construction

● Integrated Intel® Core i5-6300U/2.40GHz dual-core quad-thread processor ● 2x SODIMM DDR4 2133MHz memory, supports up to 32GB ● 2x HDMI, 1x VGA, supports triple display output ● 2x Intel I210AT Gigabit Ethernet ports ● 6x RS232 serial ports; 2x RS232 DB9 ports supporting CAN, 4x RS232/485 on 2x 10-pin Phoenix connectors ● 2x 10-pin Phoenix connectors (including 4x input/4x output GPIO/4x COM/5V) ● 7x USB 3.0, 1x USB 2.0 internal ● Supports 9~36V wide voltage input

● Integrated Intel® i5-7360U/2.30GHz Dual-Core Quad-Thread Processor ● 2*SODIMM DDR4 2133MHz memory, supports up to 32GB. ● 1*HDMI1.4, 1*VGA, support dual display ● 2*Intel I210 Gigabit power port ● 6*RS232 DB9 serial port, COM5/6 support RS485/422/CAN ● 1*12PIN Phoenix terminal (including four in four out GPIO/switch/5V signal) ● 4*USB3.0, 2*USB2.0, 1*USB2.0 built-in ● DC12V power input ● Fanless cooling structure, all aluminium alloy material

● Integrated Intel® i5-7360U/2.30GHz Dual-Core Quad-Thread Processor ● 2*SODIMM DDR4 2133MHz memory, supports up to 32GB. ● 1*HDMI1.4, 1*VGA, support dual display ● 2*Intel I210AT Gigabit power port ● 6*RS232 DB9 serial port, COM5~COM6 support RS232/RS485. ● 4*USB3.0, 4*USB2.0 ● DC 12V input ● Fanless cooling structure, all aluminium alloy material

●Integrated Intel® i3-8145U / 2.10GHz dual-core, four-thread processor ●2*DDR4 SODIMM 2400MHz memory, with a maximum support of 64GB ●1HDMI, 1VGA, supporting dual displays ●8*Intel I210 Gigabit Ethernet ports, 4 of which support POE ●1RS232/485 DB9 serial port, 1RJ45 serial port ●4USB3.0, 3USB2.0, and 1 built-in USB2.0 ●4-input 4-output GPIO ●Power supply supporting wide voltage input of 9~36V ●Fanless heat dissipation structure, full aluminum alloy material

● Integrated Intel® Celeron J6412/2.00GHz quad-core, quad-thread processor. ● 2*SODIMM DDR4 2400MHz memory, supports up to 16GB. ● 1*HDMI1.4, 1*VGA, support dual display ● 2*Intel I226 Gigabit Ethernet port, support Wake-on-LAN and PXE function. ● 6*RS232 DB9 serial port, COM3~COM6 support RS232/RS485, COM5-COM6 can support CAN. ● 1*12PIN Phoenix terminal, four in four out GPIO, switch, 5V ● 5*USB3.0, 3*USB2.0, 1*USB2.0 built-in ● Support 9~36V wide voltage input

●Integrated Intel® Celeron 3865U/1.80GHz dual-core, dual-threaded processor. ●2*SODIMM DDR4 2133MHz memory, supports up to 32GB. ●1*HDMI, 1*VGA, 1*DVI, support triple display ●2*Intel I211 Gigabit power port ●10*RS232 DB9 serial port, COM5~10 support RS485, COM9~10 can support CAN (need to load CAN module) ●1*12PIN Phoenix terminal, four in four out GPIO,switch,5V ●4*USB3.0, 3*USB2.0, 1*USB2.0 built-in ●Support wide voltage 9~36V input.
